RF-7050TVW-2KC1

Product details
Overview
Quick Details
Warranty:
1 year
Place of Origin:
Guangdong, China
Brand Name:
RF4
Model Number:
RF7050TVW-2KC1
Theory:
Stereo Microscope
Drawtube:
Trinocular
Product name:
RF4 2K camera double-arm boom stand trinocular microscope
Magnification:
7-50X
Eyepiece:
10X/22mm
Objective lens:
2x/0.5x (Additional purchase)
Light source:
144 LED Ring Light
Focusing System:
continuou zoom
Color:
Green
Working distance:
100mm
Weight:
21kg
Camera:
2K FULL HD CAMERA
Supply Ability
Supply Ability
1000 Piece/Pieces per Month
Packaging & Delivery
Port
guangzhou
Lead Time:
Quantity(sets)1 - 10>10
Est. Time(days)14To be negotiated
Specification
item
value
Warranty
1 year
Certification
CE
Place of Origin
China

Guangdong
Brand Name
RF4
Model Number
RF-7050TVW-2KC1
Theory
Stereo Microscope
Drawtube
Trinocular
Product name
RF7050TVW double-arm boom stand trinocular microscope
Magnification
7-50X
Eyepiece
10X/22mm
Objective lens
2x/0.5x (Additional purchase)
Light source
144 LED Ring Light
Focusing System
continuou zoom
Color
Green
Working distance
100mm
Weight
21kg
Camera
2K FULL HD camera
Product Description
Magnification:continuous zoom 7X to 50X
Head: 45-degree inclined 360-degree swiveling trinocular
Eyepiece: WF10X/22MM
Barlow Lens: 0.5X & 0.7&2.0X(optional)
Objective: 0.7-5.0X
Camera connector:0.5X ctv
Monitor and eyepiece. Synchronous zoom
Camera: 2K FULL HD CAMERA
Boom Stand: 51cm double-arm (overall length: 76cm)
41cm high pillar, 200mm*245mm solid cast steel base
Accessories: 144 adjustable led light & dust proof Lens
Eyepiece
(Standard Configuration)
(Auxiliary Observation)
0.5X
2X
Working Distance
100mm
Working Distance
165mm
Working Distance
30mm
Magnification
Field of View
Magnification
Field of View
Magnification
Field of View
10X/22
Standard Configuration
7X-50X
4.4-31.4mm
3.5X-25X
8.8-62.8mm
14X-100X
2.2-15.7mm
20X/10
14X-100X
1.0-7.1mm
7X-50X
2.0-14.2mm
28X-200X
0.5-3.5mm
LED RING LIGHT
instructions
Input
AC 100-240V , 50/60Hz
Output
DC 12V ,
Max output
4.5W-6W
Plug
EU/US
LED
144 LEDs
Illumination
Over 30000-35000Lux
Color Temperature
6000-7000K
Light color
BLACK
Inside diameter
60mm
Package
144-LED Lamp Ring
Power Adapter

parameters

1. Imaging element 2K 1/2.8 inch CMOS, effective pixel 1920X1080, frame rate 60 frames/SEC, resolution 900 lines.
2. Using CS lens interface, can choose any CS lens interface.
3.Power input: +5V to +12V DC, +5V maximum working current 400mA, +12V maximum working current 200mA.
4.HD: Monitor HD cable interface
5.USB: USB drive port
6.It has the function of taking pictures and recording videos
Packing & Delivery
Packing Detail:carton within foam inside or wooden box;
Shipping: 2~3 day after confirm payment;
3-5 workdays shipping from China by Air/Express(DHL,FedEx,UPS,EMS etc;
We can arrange shipment by sea. Minium CBM requirement : 1 CBM.
Our Services
1.We Will provide you User manual in English or operating videos for free ;
2.24 hours technical support by email or vedio call via wechat or skype;
3. Free training to make sure you master the operating of our products;
4. OEM/ODM accept . But the MOQ of OEM/ODM is 200 sets.
